Power-supply

Manufacturer: Gwinstek

Model: APS-7000 Series Programmable Linear AC Power Sources

Features

4.3-inch TFT-LCD Output capacity : APS-7050(500VA、310Vrms、4.2Arms)；

APS-7100 (1000VA、310Vrms、8.4Arms)；APS-7200(2000VA、310Vrms、16.8Arms)；APS-7300 (3000VA、310Vrms、25.2Arms)；

Output augmentation by options (0~600Vrms/45~999.9Hz) Low Ripple & Noise Measurement and test functions include VOLT、CURR、PWR、SVA、IPK、IPKH、FREQ、PF、CF Support a small AC current measurement 2mA ~ 35A, Min. resolution 0.01mA(APS- 7050& APS-7100) Reverse Current Alarm Function 10 sets of Sequence function to Edit Output Waveforms/ 10 sets of simulate mode to Rapidly Simulate Transient Power Supply/ 10 sets of Program mode to Define Measurement Sequence/ 10 sets of Panel Memory Function Automatic Execution of Sequence、Simulate、Program mode and Output Function when the Power is on Standard Interfaces: LAN, USB Host, USB Device (APS-7200 and APS-7300 models only) Optional Interfaces: GPIB (APS-001)；RS-232 / USB CDC(APS-002 for APS-7050& APS-7100 only)；RS-232(APS-007 for APS-7200& APS-7300 only)
